General Description
:
A range of high quality aluminium foil tapes for a variety of insulation
applications, most commonly used in the building and construction industry.
There is a choice of adhesives, either hot melt for maximum adhesion but limited
temperature resistance, or pure acrylic with superior temperature performance.
Some grades are supplied on a liner, others are available self-wound (without
a liner).
| 1012 | 1312 | 1325 | |
| Aluminium Substrate | |||
| Adhesive | Hot Melt | Pure Acrylic | Pure Acrylic |
| Thickness - Foil - Adhesive - Total |
- 0.030mm 0.035mm 0.065mm |
- 0.030mm 0.030mm 0.060mm |
- 0.040mm 0.025mm 0.065mm |
| Liner wound | Yes | Yes | No - self |
| Adhesion | 31N/25mm | 24N/25mm | 24N/25mm |
| Temp. Range (°C) | -10 / +60 | -40 / +120 | -40 / +120 |
| Availability | upon order | upon order | in stock |
 |
1012 Aluminium Foil / Film / Square Scrim Laminate Tape
Applications:
Aluminum Foil/Acrylic + Liner, Used in the construction industry. The foil scrim laminate has been approved to B.S. 476 fire standards. Test Methods : BS 3924:1978
Average Specifications: |
| Specifications | |
| Thickness, adhesive plus carrier | 0.19mm |
| Foil / film laminate (* The foil scrim laminate has been approved to B.S476 fire standards) | 0.13mm |
| Adhesive Type | Ruber Resin |
| Release liner weight | 62 g/m² |
| Peel Adhesion | 1200 N/m |
| Polyester Loop Tack | 1000 N/m |
| Release from Liner | 10 N/m |
| Tensile Strength, Machine Direction | 4000 N/m |
| Tensile Strength, Cross Direction | 2100 N/m |
| Elongation at Break | 5 % |
| Service Temperature Range | - 10 to 60 °C |
| Recommended Application Temperature Range | 5 to 25 °C |
| Moisture Vapour Permeability | Less than 1 g per m², 24h at 40 °C, 90 % R.H |
| Sheer Adhesion, 1 Kg @ 23 °C | 15 Hours |
| Shelf Life | 12 Months |
| Burst Strength | 200 kPa DIN53113 |
| Corrosion 60C, 95% R.H. 24 hour | Nill |
| Absorption of Water (Cobb/60") | ~ 0 |
| Water Vapour Permeability g/m²/24 hour | 0.5 |
| Infrared Reflectivity | 85% |
| Burning Class (in connection with suitable Glass Wool and adhesive | Class 0 BS 476 |
 |
1312 INTERLEAVED 30 MICRON ALUMINIUM TAPE, ACRYLIC ADHESIVE WITH LINER
Applications:
Aluminum Foil/Acrylic + Liner, high quality, 65mm x 50m, Interleaved 30 micron , pure acrylic with superior temperature performance, for a variety of insulation applications, most commonly used in the building and construction industry. Strong, flexible aluminium foil tape on silicon paper liner for use on most surfaces. Aggressive acrylic-based adhesive, flame retardant and excellent temperature performance. Use for jointing insulation panels, sealing off air conditioning and cool/warm air flow ducting, sealing joints in ducting providing a flame-retardant vapour proof barrier. Also ideal for general repairs to gutters, down-pipes, ducting and other surfaces. UV-resistant and waterproof. Temperature range from -40 °C to +120 °C. Installation as part fire protection system, open state cavity barrier insulation panels. Aluminum Foil has been approved to B.S. 476 fire standards. Test Methods : BS 3924:1978. Free Postage and Packaging UK Mainland only.
Average Specifications: |
| Specifications | |
| Thickness, adhesive plus carrier | 0.07mm |
| Foil Thickness (* The foil scrim laminate has been approved to B.S476 fire standards) | Level 3 |
| Adhesive Type | Acrylic |
| Release liner weight | 62 g/m² |
| Peel Adhesion | 400 N/m |
| Polyester Loop Tack | 800 N/m |
| Release from Liner | 10 N/m |
| Tensile Strength, Machine Direction | 1500 N/m |
| Elongation at Break | 3 % |
| Service Temperature Range | - 40 to 120 °C |
| Recommended Application Temperature Range | 5 to 50 °C |
| Moisture Vapour Permeability | Less than 1 g per m², 24h at 40 °C, 90 % R.H |
| Sheer Adhesion, 1 Kg @ 23 °C | 60 Hours |
| Shelf Life | 12 Months |
| Burning Class (in connection with suitable Glass Wool and adhesive | Class 0 BS 476 |
 |
1325 Aluminium Foil without liner Acrylic Adhesive
Applications:
Used in the construction industry, installation as part fire protection system, open state cavity barrier insulation panels. The foil scrim laminate has been approved to B.S. 476 fire standards. Test Methods : BS 3924:1978 Average Specifications: |
| Specifications | |
| Thickness, adhesive plus carrier | 0.065mm |
| Foil Thickness (* The foil scrim laminate has been approved to B.S476 fire standards) | 0.040 |
| Adhesive Type | Emulsion Acrylic |
| Peel Adhesion | 400 N/m |
| Polyester Loop Tack | 800 N/m |
| Tensile Strength, Machine Direction | 2000 N/m |
| Elongation at Break | 5 % |
| Service Temperature Range | - 40 to 120 °C |
| Recommended Application Temperature Range | 5 to 25 °C |
| Moisture Vapour Permeability | Less than 1 g per m², 24h at 40 °C, 90 % R.H |
| Sheer Adhesion, 1 Kg @ 23 °C | 60 Hours |
| Shelf Life | 12 Months |
| Test Methods: | BS 3924:1978 |
 |
Self-wound Aluminium Foil Tape.
Applications:
Used in the construction industry, installation as part fire protection system, open state cavity barrier insulation panels. The foil scrim laminate has been approved to B.S. 476 fire standards. Extensively used in the Double Glazing Industry for a professional finish on the edge of sealed units. BS 5713 has been achieved on customers sealed units, in conjunction with this product. Surfaces to be bonded must be clean, dry and free from dust. Storage : Normal room temperature
Average Specifications: |
| Specifications | |
| Widths Available: | A comprehensive range from 6 to 100mm |
| Standard Length: | 45m |
| Film Thickness: | 38 μM |
| Total Thickness: | 130 μM |
| Tensile Strength: | 65 N/25mm |
| Peel Adhesion on Steel: | 15 N |
| Elongation at Break | 3.2 % |
| Shear | >200 hrs |
| Loop Tack: | 12.7 N/25mm |
| Application Temperature: | 0 °C to 40°C (Can be applied at temps down to 0 °C as long as surface is free from ice or moisture) |
| Service Temperature: | -20 °C to 110 °C |
| Moisture Vapour Permeability: | Less than 1 g/m2/24 hours |
| Fire Rating | Class O |
| 0316 Aluminium Foil Band Butyl Tape / Foil Laminate / Synthetic Rubber Sealing / Flashing Tape | ||||||
0316
Foil Laminate Butyl |
35 Adhesion (N/25mm) | 150 Tensile (N/25mm) | -40 / +90 Service Temperatufont-size: 10pt" color="#990000">Sheer Adhesion, 1 Kg @ 23 °C | 60 Hours | ||
| Shelf Life | 12 Months | |||||
| Class '0' Fire Rating | BS.476 Parts 6 and 7 / UL723 | |||||
FSK (Foil Scrim Kraft) Tape
General Description:
The tape is based on a 7 micron aluminium foil, reinforced with a 3 way fibreglass scrim kraft, and with a water based acrylic adhesive. It is a self-adhesive tape.
Applications:
Used for sealing joints and seams against moisture and vapour on foil jacketing insulation Web: www.printernational.co.uk ~ Tel: +44 (0)20 8050 8069 ~ E-mail: pr@printernational.co.uk
A reinforced aluminium foil tape.
HS Code:76.07.20.00
Specifications
Aluminium Foil Substrate
7 microns
Fibreglass Scrim Kraft
-
Waterbased Acrylic Adhesive
Yes
Release Paper
60 g/m²
Total Thickness
140 microns
Peel Adhesion
14 N/25mm width
Roller Tack
0.1N/25mm width
