General Description
Product Benefits
Average Specifications
|
|
Specifications
|
|
Available Thickness
|
0.200mm - 0.8mm
|
|
Shear
|
>1495.0 (FTM 8 @ 40 ° C 10N/in2)
|
|
Release liner Thickness
|
0.080mm
|
|
Adhesion (n/25mm)
|
20
|
|
Test Methods
|
BS 7116
|
|
180° peel adhesion
|
20.0 (FTM1) - 180o N/ 25mm< or >1000 N/m
|
|
Polyester loop tack
|
>1000 N/m
|
|
Liner release
|
>10 N/m
|
|
Elongation at break
|
4%
|
|
Specific Gravity
|
0.98 g/cm3
|
|
Softening Point
|
85 ° C
|
|
Cohesion
|
0.6mm Nmm2
|
|
Tack
(Roller Ball Method) |
30mm
|
|
Service Temperature
|
-10 to +60 ° C (apply at 10 ° C and above)
|
|
|
|
Description: Double Sided Tape Chemical constituents: A Solvent-less adhesive bonding tape based on a blend of synthetic rubber and resin. A white silicone coated paper is used as a liner. The product is wound into rolls. Hazardous Ingredients: None. |
|
|
|
|
Health hazards: No danger to health under normal conditions of use. Environmental hazards : No particular risk for the environment on condition that the recommendations under "Disposal Considerations" later define. Physical and chemical hazards: No particular risk Specific hazards: Hazard warning not required according to the provisions in annex VI of the directive 67/548/CEE |
|
|
|
|
Inhalation: No special measures required Skin: Wash with soap and water. Eyes: Wash out with water Ingestion: No known toxicity |
|
|
|
|
Extinguishing Media: No restriction. Specific dangers : No specific danger. Protective Equipment for fire-fighters: No specific equipment required |
|
|
|
|
Individual precautions: No special measures required. Cleaning and removal: Take up mechanically |
|
|
|
|
Manipulation: Respect normal rules for industrial hygiene. Technical measures for storage : No special measures required. Storage conditions: Store in a cool dry place between +10°C and +30°C, humidity between 30% and 70% Incompatible substances: None known Packaging: Store in original packaging Packaging materials: Paper or siliconised film carton |
|
|
|
|
Technical measures: No special measures required if good respect of normal rules for industrial hygiene and security. Individual protection equipment: No special measures required if good respect of normal rules for industrial hygiene and security. |
|
|
|
|
Form: Solid. Supplied on a roll. pH: Not applicable. Odour: slight. Boiling Point: Not applicable. Melting Point: Indistinct. Softens at > 85 ° Centigrade. Flash Point: Not applicable. Flammability (Solid, Gas): Not applicable. Autoflammability: Not Applicable. Explosive properties / oxidising properties: Not an oxygen carrier according to CEE criteria. Vapour Pressure: Not applicable. Specific Gravity: 0.98g/cm3. Solubility in water: Insoluble. Soluble in: Aromatic and aliphstic hydrocarbons. Partition Coefficient: Not applicable. |
|
|
|
|
Thermal Decomposition: Above 200 ° Centigrade. Hazardous reactions: No special measures required if good respect of normal rules for industrial hygiene and security. |
|
|
|
|
Serious toxicity / Local effects: All the ingredients are essentially non-volatile and of no toxicity. The
major ingredients can be regarded as essentially harmless. |
|
|
|
|
Mobility: No Known hazards. |
|
|
|
|
Destruction / elimination: Incinerate only in purpose built authorised incinerators. Packaging: Material should be treated as household waste or as recycling material. Decontamination / cleaning: No necessary cleaning precautions before elimination. N.B.: Landfill in accordance with local regulationse. |
|
|
|
|
Complies with The Montreal Protocol for the elimination of CFC's Complies with The US Clean Air Act amendment of 1990 No labeling is required for this material under EEC regulations |
|
0480 >
The product can also be supplied in 4kg blocks for extrusion by customers, under our product code "0480".
