8030 White PVC Filmic Tape, Solvent Acrylic Adhesive, Amber Liner
8030 White PVC Filmic Tape, Solvent Acrylic Adhesive, Amber Liner
  • Designed to provide strength and dimensional stability to weak foams and gaskets/die cuts. These tapes will help prevent stretch and may increase the tensile strength of a final construction. The film has the added benefit of providing a chemical barrier to plasticizer and oils etc, which over a period of time may affect the performance of the adhesive. Four films are available, Polypropylene, Polyester, Polythene and PVC with Polyester providing the greater strength. All available in various gauges and colours upon request.
  • Good balanced adhesive system providing good bond strength during actual application but when required clean removability. Roll lengths are available to a maximum 1500 metres on a 3 inch core and a maximum of 150 metres on a 1 inch core. Products can be bobbin wound to 5000 metres
    • Typical Value
    Unit
    Thickness , adhesive + carrier
    0.275
    mm
    Release liner thickness
    0.66
    mm
    180 degree peel adhesion: open side
    1200
    N/m
    180 degree peel adhesion: closed side
    1200
    N/m
    Polyester loop tack: open side
    1250
    N/m
    Polyester loop tack: closed side
    1250
    N/m
    Liner release
    3
    N/m
    Tensile strength
    2000
    N/m
    Elongation at break
    75
    %
    Service temperature, continious
    -20 to + 120
    °C
    Minimum application temperature
    10 < 1min
    °C
    Static Shear adhesion, 1 Kg @ 23 °C, 25mm square
    >100
    Hours
    Static Shear adhesion, 2 Kg @ 23 °C, 25mm square
    >55
    Hours
    Shear adhesion failure temperature, 100g load
    >100
    °C,
    Shear adhesion failure temperature, 250g load
    >100
    °C,
    Shelf Life
    12
    Months
  • Roll length: 50 meters
  • Roll width: 3mm, 6mm, 16mm, 20mm
  • Packaging: Flow pack with label or plastic bag
    • The rolls should be stored flat on their cut edges in the original packaging. The product must be protected from dust, heat, moisture, direct sunlight and solvent fumes. Storage temperature about 20°C. Shelf Life 12 months.
    Contact us by phone, e-mail for any adhesive tape requirement
    Web: www.printernational.co.uk ~ Tel: +44 (0)20 8050 8069 ~ E-mail: pr@printernational.co.uk
